The ATMEGA2560 is a low-power CMOS 8-bit microcontroller based on the AVR enhanced RISC architecture. By executing powerful instructions in a single clock cycle, the ATMEGA2560 achieves through puts approaching 1 MIPS per MHz allowing the system designer to optimize power consumption versus processing speed.

The high-performance, low-power 8-bit AVR RISC-based microcontroller combines 256KB ISP flash memory, 8KB SRAM, 4KB EEPROM, 86 general purpose I/O lines, 32 general purpose working registers, real time counter, six flexible timer/counters with compare modes, PWM, 4 USARTs, byte oriented 2-wire serial interface, 16-channel 10-bit A/D converter, and a JTAG interface for on-chip debugging. The device achieves a throughput of 16 MIPS at 16 MHz and operates between 4.5-5.5 volts.

By executing powerful instructions in a single clock cycle, the device achieves a throughput approaching 1 MIPS per MHz, balancing power consumption and processing speed.

Features

• High-performance, Low-power Atmel AVR 8-bit Microcontroller


• Advanced RISC Architecture

- 133 Powerful Instructions

- 32 � 8 General Purpose Working Registers + Peripheral Control Registers

- Fully Static Operation

- Up to 16MIPS Throughput at 16MHz

- On-chip 2-cycle Multiplier

• High Endurance Non-volatile Memory segments

- 64K/128K/256KBytes of In-System Self-Programmable Flash

- 4Kbytes EEPROM

- 8Kbytes Internal SRAM

- Write/Erase Cycles:10,000 Flash/100,000 EEPROM

- Optional Boot Code Section with Independent Lock Bits

• In-System Programming by On-chip Boot Program


• True Read-While-Write Operation

- Programming Lock for Software Security

• JTAG (IEEE std. 1149.1 Compliant) Interface

- Boundary-scan Capabilities According to the JTAG Standard

- Extensive On-chip Debug Support Atmel-8151

- Programming of Flash, EEPROM, Fuses and Lock Bits through the JTAG Interface

• Peripheral Features

� Two 8-bit Timer/Counters with Separate Prescalers and Compare Modes

� Four 16-bit Timer/Counter with Separate Prescaler, Compare- and Capture Mode

� Real Time Counter with Separate Oscillator

� Four 8-bit PWM Channels

� Six/Twelve PWM Channels with Programmable Resolution from 2 to 16 Bits

� Output Compare Modulator

� 8/16-channel, 10-bit ADC (

� Two/Four Programmable Serial USART

� Master/Slave SPI Serial Interface

� Programmable Watchdog Timer with On-chip Oscillator

� On-chip Analog Comparator

� Byte Oriented 2-wire Serial Interface

� Interrupt and Wake-up on Pin Change

• Special Microcontroller Features

� Power-on Reset and Programmable Brown-out Detection

� Internal Calibrated RC Oscillator

� External and Internal Interrupt Sources
